Ultra HD 6x2 HDMI Matrix Switch with ARC Support (HD-602)
OREI HD-602: 6-In-2-Out HDMI Matrix Switch with ARC
- HDMI 2.0, HDCP 2.2 compliant
- Video resolutions up to 4K@60Hz
- 2.9Gbps video bandwidth
- Audio extraction through Optical and Analog
- Output A support ARC function
- Control through the included remote or the buttons on the device
- Strong build
- Plug-and-play setup
The HD-602 Matrix switch lets you connect up to 6 media devices and distribute them to 2 displays. It supports video resolutions up to 4K@60Hz 4:2:0 and 4K@30Hz 4:4:4, compliant with HDMI 2.0 and HDCP 2.2 standards, featuring a 2.9Gbps video bandwidth. It supports audio extraction via Optical and Analog, with Output A supporting ARC functionality. Audio format changes are possible using the EDID button. Control is simple with the included remote or the buttons on the device. The HD-602 is ideal for any home theater or commercial setup.
[shortdes]
- 2.9Gbps video bandwidth
- Video resolutions up to 4K@60Hz
- Output A support ARC
[/shortdes]
[tab]
CONNECTIVITY
| INPUT: | 6 × HDMI [Type A, 19-pin female] | |
| OUTPUT: | 2 × HDMI [Type A, 19-pin female] | |
| 1 x OPTICAL [S/PDIF, female] | ||
| 1 × L/R [3.5mm Stereo Mini-jack] |
PACKAGE CONTENTS
| 1x HD-602 |
| 1x Remote |
| 2x Mounting ears |
| 1x Power Adapter |
| User Manual |
SUPPORTED HDMI CABLES
| HDMI 2.0 / 2.1 | We recommend using high-quality HDMI 2.0 / 2.1 cables under 30 feet for optimum performance |
EXTENDING DISTANCE
| 4K@60Hz: | 30 Feet |
VIDEO OUTPUT
| Video Bandwidth: | 2.97 Gbps |
| Video Resolutions: | Up to 4K@30Hz |
ADDITIONAL FEATURES
| CEC: | No |
| ARC: | Yes |
| USB KVM: | No |
| PoC/PoE: | No |
| IR Control: | Yes |
| Downmix: | No |
| Downscale: | No |
| Over IP: | No |
| HDBaseT: | No |
| RS-232: | No |
AUDIO SUPPORT
| HDMI Audio Formats: | PCM 2.0, 5.1, 7.1, Dolby 5.1, DTS5.1, Dolby TrueHD, DTS-HD |
| Optical Audio Formats: | PCM 2.0, 5.1, Dolby 5.1, DTS5.1 |
| Analog Audio Formats: | PCM 2.0 |
COMPLIANCES
| HDMI Compliance | HDMI 2.0 |
| HDCP Compliance | HDCP 2.2 |
POWER
| Power Consumption: | 10W (Max) | |
| Power Supply: | Input: AC 100-240V 50/60Hz | |
| Output: DC 5V/2A |
DIMENSIONS & WEIGHT
| Length: | 250mm / 9.84in | |
| Width: | 110mm / 4.33in | |
| Height: | 26mm / 1.02in | |
| Weight: | 720g / 1.58lbs |
PROPERTIES
| Color: | Black |
| Housing: | Metal Enclosure |
WARRANTY
| 1-Year Manufacturer's Warranty |
[/tab]
