- 3 Inputs - 1 output HDMI KVM switch \n
- Video resolution up to 4K@60Hz - HDR \n
- Supports KVM \n
- Compliance: HDMI 2.0 - HDCP 2.2 \n
Ultra HD 4K 3x1 HDMI KVM Switch Keyboard & USB Peripheral Control (UKM-301C)
UKM-301C HDMI KVM Switch with USB-C
- Supports 4K resolutions – up to 3840 x 2160 @ 60Hz
- Support USB-C to HDMI video signal
- 3 inputs 1 outputs (Inputs：1*USB–C / 2*HDMI & 2*USB2.0-Type A )
- Charge devices with up to 1.5A power delivery on USB-C port
- KVM function Share one set of mouse ,keyboards , screen and operate on individual source
- Support HDMI 2.0 standard /HDCP 2.2 compliant
- High frequency range：25MHz~600MHz
- DTS® HD, Dolby® TrueHD digital audio compliant
- Expand 2 HDMI sources on your HDTV devices
- USB 3.1 GEN1 TYPE C input supports Android Phone、PC and Mac , I pad pro_2019
- Supports Samsung DeX® Mode & Huawei MUEI mode
Few sample applications:
OREI UKM-301C 4K at 60Hz KVM switch ideal device for multitasking on a Single Monitor, You can take control of three devices such as PC, Computer, Laptop, Android Smartphones, Streaming Box, PS4/PS5 gaming devices or 4K Blu-ray Players on a single Monitor. You can use a set of USB Keyboard to control everything.
Support resolution up to 4K@60Hz YUV4:4:4 chroma sampling, making display image more exquisite and realistic, really give a feast for your eyes.
It also supports 3D and 1080P or lower resolution. 4K KVM Switch can full meet the needs of family and Office. Supports PCM, Dolby True HD, DTS-HD Master Audio up to 7.1 Ch. Digital and analog Audio output. Type C input supports Android Phones, PC and Mac, iPad Pro, For Video Output through USB-C Port, it must support DP Alt Mode.
[summary]
- 2 HDMI input + Dual USB and 1 USB-C into 2 output Matrix Switcher
- Full 18G bandwidthbr>
- USB 3.1 GEN1 Type C input supports Android Phones for Video Output through USB-C Port
[/summary]
[tab]AUDIO AND VIDEO
| Inputs Ports | USB–C DP Alt mode (Type C 24-pin female) |
| HDMI Receiver (Type A 19-pin female) | USB-A Transmitter (USB 2.0 TYPE A) | |
| HDMI Receiver (Type A 19-pin female) | USB-A Transmitter (USB 2.0 TYPE A) | |
| Output Ports | HDMI Transmitter (Type A 19-pin female) | USB-A Transmitter (USB 2.0 TYPE A) | USB-A Transmitter (USB 2.0 TYPE A) |
| Video Bandwidth | 18Gbps |
| Video Resolution: | 4K@60Hz(4096x2160), 1080P@60Hz(1920x1080) |
| Color Space: | RGB, YCbCr 4:4:4, YCbCr 4:2:2, YCbCr 4:2:0 |
| HDMI Audio Formats | PCM 2ch / PCM5.1 /PCM7.1, DTS /DTS-HD, Dolby 5.1 /Dolby 7.1/ Dolby TrueHD |
COMMUNICATION AND CONTROL
| HDMI and USB Compliance | HDMI and USB 2.0 |
| HDCP Compliance | HDCP 2.2 |
POWER
| Power Supply: | DC INPUT 5V / 3A / Micro USB |
| Power Consumption | Main unit power consumption 0.3A, USB-C charging 1.5A, USB-A charging 0.5A, 2.3A(Max./Charger) |
ENVIRONMENTAL
| Operating Temperature: | 0°C to 43°C (32°F to 109.4°F) |
| Storage Temperature: | -20°C to 60°C (-4°F to 140°F) |
| Relative Humidity | 10~80 % RH |
DIMENSIONS & WEIGHT
| Height | 18.6 mm |
| Width | 170mm |
| Depth | 62 mm |
| Weight | 114g |
REGULATORY
| Safety and Emission: | CE | FCC | RoHS |
PACKAGE CONTENTS
| 1 × UKM-301C 3x1 HDMI KVM Switch |
| 1 × Power Adapter |
| 1 × User Manual |
Warranty
| 1 - Year Manufacturer's Warranty |
[tab1]
FAQs
You can use standard HDMI cables up to 15 feet and high quality cables up to 30 feet.
However, you can use fiber optic active HDMI cables up to 200 feet. If its not a high quality cable then you may lose the signal in some instances.
You can use standard HDMI cables up to 15 feet and high quality cables up to 30 feet.
However, you can use fiber optic active HDMI cables up to 200 feet. If its not a high quality cable then you may lose the signal in some instances.
No, our switchers aren't compatible with capture cards
Yes, the included power adapter does support 220V
